Construction and prototype construction
Your product design is in place and you are looking for a partner who plans and designs all production-related tools and devices for you? Would you like to implement a CAD design with properties close to series production?
How about making the brute two-dimensional skull logo of the Dieselbrothers© tangible?
Human skull scan
The basis was an image of the logo. In order to be able to match the proportions, the scan of a human skull was used as the support geometry. The back of the head was modeled. The logo is scaled to the correct proportions.
From 2D to 3D
The base curves were derived from the logo. They form the basis of surface modeling. The beard and face are created and modeled based on the real scan. The implementation in CAD has been completed.
Milling and finishing
Finally, the skull is milled from an aluminum block using a 4-axis CNC milling machine.
